Description:
This Temperature Control Controller can used in the (liquid, mold, space) and other control heating, also can be used (box, the device, water, pet rooms, air conditioning) and other control refrigeration.
Specification:
Model: W1209 Temperature control mode: ON / OFF
Temperature range: -50-110 °C
Resolution : When temperature is 0.1, the resolution is -9.9~99.9, other temperature segment is 1°C Control accuracy: 0.1 °C Hysteresis accuracy: 0.1°C Refresh rate: 0.5S High temperature protection: 0-110°C Supply voltage: DC 12V Static current: 35MA, attract current 65MA Output voltage: DC 12V Output power: 10A relay Measurement input: NTC (10K 0.5%) waterproof sensor Environmental requirements: -10 ~ 60 °C Humidity: 20% -85%
Setting Table | |||
Press The "SET" Key To Enter The Main Menu | |||
Code | Code Description | Setting Range | The Factory Setting |
P0 | Cooling / Heating | C / H | C |
P1 | Hysteresis setting | 0.1 - 15 | 2 |
P2 | Maximum set cap | 110 | 110 |
P3 | Minimum set limit | -50 | -50 |
P4 | Temperature correction | -7.0 ~ 7.0 °C | 0 |
P5 | Delayed start time | 0 - 10 minute | 0 |
P6 | High temperature alarm | 0 - 110 °C | OFF |
Closed state to press "+ -" to power, can restore to the factory settings |
Package Contents:
1 x Digital temperature control switch
