Wago (2092-1375) Wire-To-Board Terminal Block, 5 mm, 5 Ways

Wire-To-Board Terminal Block, 5 mm, 5 Ways, 24 AWG, 12 AWG, 2.5 mm², Push InProduct OverviewThe 2092-1375 is a 5-pole 16A light grey wire-to-board eCOM pluggable TerminalBlock with through-hole right-angle block orientation and Push-in CAGE CLAMP®wire connection technology. It is designed with angled solder pins withoutgripping plate. It has tin-plated electrolytic copper contact with glassfibre-reinforced polyphthalamide insulation and a chrome-nickel-plated steelclamping spring.Universal connection of all conductor typesSimple push-in termination of solid and ferruled conductorsEasy-to-use design does not require special toolsAbility to wire while mated or unmatedIntegrated test ports for testing parallel to conductor entryCustom-installed solder pinsUL94V-0 Flammability rating-60 to 100°C Operating temperature rangeApplicationsIndustrialProduct InformationPitch Spacing: 5mmNo. of Positions: 5WaysWire Size AWG Min: 24AWGWire Size AWG Max: 12AWGConductor Area CSA: 2.5mm²Wire Connection Method: Push InRated Current: 16ARated Voltage: 320VBlock Orientation: Through Hole Right AngleProduct Range: -
