Wago (2716-103) Wire-To-Board Terminal Block, 10 mm, 3 Ways

Wago (2716-103) Wire-To-Board Terminal Block, 10 mm, 3 Ways

8 available / new
R455.00
Shipping
R35.00 Standard shipping using one of our trusted couriers applies to most areas in South Africa. Some areas may attract a R30.00 surcharge. This will be calculated at checkout if applicable.
Check my rate
The seller allows collection for this item. Buyers will receive the collection address and time once the order is ready.
The seller has indicated that they will usually have this item ready to ship within 3 business days. Shipping time depends on your delivery address. The most accurate delivery time will be calculated at checkout, but in general, the following shipping times apply:

Standard Delivery
Main centres:  1-3 business days
Regional areas: 3-4 business days
Remote areas: 3-5 business days
Seller
Buyer protection
Get it now, pay later

Product details

Condition
New
Location
South Africa
Product code
2667142
Bob Shop ID
645127558
Wire-To-Board Terminal Block, 10 mm, 3 Ways, 16 AWG, 6 AWG, 16 mm², Push InProduct OverviewThe 2716-103 from Wago is a gray colour, 3 pole CAGE CLAMP PCB terminal blockwith operating lever. It is a high current PCB terminal strip withlever-actuated CAGE CLAMP. This PCB terminal block is compatible to highcurrent, screw-type PCB terminal blocks. It has CCA, CSA, KEMA and cURus(Underwriters Laboratories Inc) approvals.320V rated voltage (III/3), 4KV rated impulse voltage (III/3) and 76A ratedcurrentPin spacing is 10mm, four solder pins per contact point for high mechanicalstability1.5mm² to 16mm² (16AWG to 6AWG) solid conductors (tool operated termination)1.5mm² to 16mm² (16AWG to 6AWG) fine stranded (tool operated termination)Strip length is 12mm to 13mmConductor entry angle is 30° to PCBSolder pin length/width is 4.5mm / 0.95mm x 1.2mmInsulating material is polyamide 66 (PA 66), flammability rating per UL 94 V0Clamping spring material is chrome nickel spring steel (CrNi)Contact material electrolytic copper (Ecu) and contact plating is tinApplicationsIndustrialProduct InformationPitch Spacing: 10mmWire Size AWG Min: 16AWGWire Size AWG Max: 6AWGConductor Area CSA: 16mm²Wire Connection Method: Push InRated Current: 76ARated Voltage: 320VBlock Orientation: Through Hole Right AngleProduct Range: 2716
