Model No: HW0028 |
ᅡᅠ | OS | Embedded Linux OS |
Processor | 3518EV200+H65 |
P2P (Free) | No need to preset camera, Offer free ᅡᅠP2P(ZZZZ-xxxxxx-xxxxx), Plug&play, Support ᅡᅠQR code scanning to view |
Onvif Protocol | Support ONVIF 2.4 |
Multi-device function | Support 12 language remote surveillance, record, alarm, wifi setting etc. |
PC client | Support remote multi-devices monitor, record, alarm etc. |
Cell Phone View | Self R&D APP, Support Iphone,Android smart Phone |
Lens | Lens Type | Lens Standard: 2.7-13.5 mm optical zoom lens |
IR-CUT | Build-in IR CUT, No color cast |
Video | Image Compression | H.264 |
Sensor | 1/3-inch 1.3-megapixel progressive CMOS sensor |
Video Parameters | Brightness, Contrast,Saturation,Exposure,sharpness,VerticalAnd Horizontal can be adjusted |
Image Frame Rate | 25fps(50HZ), 25fps(60HZ) |
First Stream | 960P-1280x960,ᅡᅠ1280x720,ᅡᅠ640x480,ᅡᅠ640x352 |
Second Stream | VGA-(640x352), (320x176) |
Night Vision | Lux | IR ON 0LUX |
Night Visibility | 22 ᅫᆭ5 IR LEDs, Night visibility up to 15 meters |
Pan/Tilt | Preset | Support 8 Preset Positions |
Rotation Angle | Pan:355ᅡᄚ, ᅡᅠTilt: 90ᅡᄚ |
Rotation Speed | Pan: Speed Range 5-30ᅡᄚ/ S; Tilt: Speed Range 5-50ᅡᄚ/ S; |
Alarm | Motion Detect | Support 4 Independent detection areas(Sensitivity can be adjustd 1-100) |
Alarm Action | SupportᅡᅠEmail Photo Alert, Snapshot and Record uploaded to FTP |
Network | Ethernet Interface | One 10/100Mbps RJ-45 |
Supported Protocol | TCP/IP,https,TCP,ICMP,UDP,ARP, IGMP,SMTP,FTP,DHCP,DNS,DDNS,NTP,UPNP,RTSP etc.</ |
