Waterproof Outdoor Surface Mounted 1-in-1-out 600V IP65 Solar PV Surge Lightning Protection DC Combiner Box (10005941)
The Waterproof Outdoor Surface Mounted Solar PV Combiner Box is a durable and reliable solution for combining and protecting multiple solar PV strings. This combiner box is designed to withstand harsh outdoor environments, with its waterproof and weather-resistant construction. It provides a safe and efficient way to connect and manage solar panels, ensuring maximum power output and system performance. The combiner box features a compact and surface-mounted design, making it easy to install and maintain. It is equipped with high-quality components and built-in surge protection, offering a secure and long-lasting solution for solar PV installations. With its advanced features and rugged design, this combiner box is an essential component in any outdoor solar power system.
1 strings DC600V use DC600V circuit breaker 2 pole 1pcs, DC600V surge protector 2 pole 1 pcs, DC1000V fuse 15A 2 pcs, solar connector 1 pair.
Product introduction
PV String DC Combiner Boxes are key components in the solar power systems, which are placed between solar modules and the inverters.
Product functions
- Simplify the physical between solar panel and inverter
- Fault current protection for each String
- Fault alarm
- Easy installation and maintenance
Product features
- Very high impact resistance
- Easy machining with normal tools
- IP65
- Wide operation temperature range
- Fire Resistance
- Non-conductive
- Good resistance to chemical corrosion
- Light weight
- Excellent insulating properties
- Cost-effective material for harsh environments
Product specifications
| Solar PV DC 1 in 1 out Combiner Box | |
| Rated voltage of photovoltaic system | DC 600V |
| Max input amp for each string | 15A |
| Input strings | 1 |
| Number of output strings | 1 |
| Waterproof grade ip65/ Lighting protection | |
| Category of test | II grade protection |
| Nominal discharge amp | 20KA |
| Max discharge amp | 40KA |
| Volt protection level | 3.2KV |
| SPD Max operation voltage | DC 600V |
| Poles | 2P |
| Structure characteristic | Plug push module |
| System | |
| Protection grade | IP65 |
| Output switch | DC circuit breaker |
| Solar connector | Standard |
| Box material | PVC |
| Installation method | Wall mounting type |
| Operating temperature | -25-+60 |
| Installation: indoors/outdoors | Yes |
| Mechanical parameter | |
| Width*hight*Depth (mm) | 215*210*100 |
