Waveshare RP2040-Tiny Dev Board

The Waveshare RP2040-Tiny Development Board is a compact and powerful microcontroller board based on the RP2040 chip by Raspberry Pi. It features a dual-core Arm Cortex M0+ processor, flexible clock speeds, ample memory, and versatile connectivity options. With GPIO pins, SPI, I2C, UART, ADC, PWM channels, and custom peripheral support, it offers extensive interface capabilities. The board supports USB connectivity, low-power modes, and easy drag-and-drop programming. It also includes features like on-chip clock and timer, temperature sensor, and floating-point libraries. Ideal for embedded systems and IoT projects, this development board packs functionality and performance into a small form factor.

Specifications

• RP2040 microcontroller chip designed by Raspberry Pi in the United Kingdom
• Dual-core Arm Cortex M0+ processor, flexible clock running up to 133 MHz
• 264KB of SRAM, and 2MB of onboard Flash memory
• Onboard FPC 8PIN connector, adapting USB Type-C port via adapter board
• Castellated module allows soldering direct to carrier boards
• USB 1.1 with device and host support
• Low-power sleep and dormant modes
• Drag-and-drop programming using mass storage over USB
• 20 × multi-function GPIO pins
• 2 × SPI, 2 × I2C, 2 × UART, 4 × 12-bit ADC, 16 × controllable PWM channels
• Accurate clock and timer on-chip
• Temperature sensor
• Accelerated floating-point libraries on-chip
• 8 × Programmable I/O (PIO) state machines for custom peripheral support

Comprehensive SDK, Dev Resources, Tutorials To Help You Easily Get Started

20 × Multi-Function GPIO Pins



What's in the box?

1 x RP2040-Tiny
1 x RP2040-Tiny-Adapter
1 x 8PIN FPC cable ~15cm

Resources

Wiki: www.waveshare.com/wiki/RP2040-Tiny
