Webly Rebel Airgun

The .177 caliber Rebel stretches 34.6 inches from end to end and weighs just 4.4 lbs. At the extreme end of the Rebel is a rubbery butt, which is attached to the ambidextrous synthetic stock by a white spacer. The stock is finished with a fine pebbly surface, giving it a matte appearance. On either side of the pistol grip and forestock is a pattern of tiny bumps to improve grip.

Forward of the pistol grip, a black plastic trigger guard surrounds a black plastic trigger and push-button safety. Forward of the trigger guard is the forestock which serves as the pumping arm to charge the action. Above the forestock is the barrel which has a plastic fitting on the end that serves as a mount for the fiber-optic front sight. Moving back along the barrel, you'll find the receiver, which is molded out of black plastic and has a dovetail on top for mount a scope or rear sight.

On the right side of the receiver is the breech. At the end of the receiver on the right side is a lever. Press it down, and the bolt springs backward, opening the breech for loading a pellet.

The pumping lever/forearm full open.

To ready the Rebel for shooting, grab the air rifle by the pistol grip with one hand and the forearm with the other. Open the forearm all the way and return it to its original position for each charging stroke. Pump the Rebel up to eight times for maximum power. When you're done pumping, click the lever on the right side of the receiver, and when the breech pops open, load a pellet and push the bolt back to its original position.

Ease the first stage out of the trigger, squeeze the second stage, and the shot goes down range.

4 pumps = 645 fps

5 pumps = 705 fps

6 pumps = 740 fps

7 pumps = 766 fps

8 pumps = 786 fps
