Weidmuller (LM3.5/03/90 3.2) Wire-To-Board Terminal Block, 3.5 mm, 3 Ways

Wire-To-Board Terminal Block, 3.5 mm, 3 Ways, 26 AWG, 14 AWG, 1.5 mm², ScrewProduct OverviewThe LM3.5/03/90 3.2 is a 3-pole 3.5mm PCB Terminal Block with clamping yokeconnection. Solder connection mount onto the PCB, M2 clamping screw and 5mmstripping length. Orange colour, 90° conductor outlet direction and tinnedCu-Leg contacts. The LM 3.50/03/90 3.2SN OR BX 1667770000 PCB terminal accepts28AWG minimum to 14AWG maximum wire size.PA insulatorUL94V-2 Flammability ratingIP20 Protection ratingApplicationsIndustrialProduct InformationPitch Spacing: 3.5mmWire Size AWG Min: 26AWGWire Size AWG Max: 14AWGConductor Area CSA: 1.5mm²Wire Connection Method: ScrewRated Current: 10ARated Voltage: 300VBlock Orientation: Through Hole Right AngleProduct Range: -
