Weidmuller (PM5.08/3/90 BLK) Wire-To-Board Terminal Block, 5.08 mm, 3 Ways

Wire-To-Board Terminal Block, 5.08 mm, 3 Ways, 26 AWG, 14 AWG, 2.5 mm², ScrewProduct OverviewThe PM5.08/3/90 BLK from Weidmuller is a through hole, 3 pole PCB terminal withleaf spring connection and 5.08mm pitch spacing. This terminal is used for wiresize ranging from 26AWG to 14AWG.Black colour housingWemid (PA) insulating materialCu-leg contact materialTinned contact surfaceNet weight of 2.356gIP20 touch safe protectionUL94 V-0 flammability ratingPressure clamp wire connection and 90° conductor outlet directionCSA, EAC approved and cULus recognisedApplicationsIndustrialProduct InformationPitch Spacing: 5.08mmWire Size AWG Min: 26AWGWire Size AWG Max: 14AWGConductor Area CSA: 2.5mm²Wire Connection Method: ScrewRated Current: 24ARated Voltage: 600VBlock Orientation: Through Hole Right AngleProduct Range:
