Weidmuller (PM5.08/3/90) Wire-To-Board Terminal Block, 5.08 mm, 3 Ways

Name: Weidmuller (PM5.08/3/90) Wire-To-Board Terminal Block, 5.08 mm, 3 Ways
SKU: 1131854
Price: 189.00 ZAR
Availability: InStock

New

4453 available

R189.00

Add to watchlist Watch

Shipping

R35.00 Standard shipping using one of our trusted couriers applies to most areas in South Africa. Some areas may attract a R30.00 surcharge. This will be calculated at checkout if applicable.
Check my rate

The seller has indicated that they will usually have this item ready to ship within 7 business days. Shipping time depends on your delivery address. The most accurate delivery time will be calculated at checkout, but in general, the following shipping times apply:

Standard Delivery

Main centres:	1-3 business days
Regional areas:	3-4 business days
Remote areas:	3-5 business days

Seller

Antwire170

93.75 % Positive ratings

Buyer protection

How you're covered

Get it now, pay later

Product details

Condition

New

Location

South Africa

Product code

1131854

Bob Shop ID

674509294

Wire-To-Board Terminal Block, 5.08 mm, 3 Ways, 26 AWG, 14 AWG, 2.5 mm², ScrewProduct OverviewThe PM5.08/3/90 is a 3-pole 5.08mm PCB Terminal Block with pressure clampconnection. PCB connector with leaf-spring wire connection system with 90°conductor outlet direction. Suitable for conductor cross-sections up to 2.5mm².Orange colour, M2.5 clamping screw, 6mm stripping length and tinned Cu-Legcontacts. The PM 5.08/03/90 3.5SN OR BX 1760500000 PCB terminal accepts 26AWGminimum to 14AWG maximum wire size.Wemid insulatorUL94V-0 Flammability ratingIP20 Protection ratingApplicationsIndustrialProduct InformationPitch Spacing: 5.08mmWire Size AWG Min: 26AWGWire Size AWG Max: 14AWGConductor Area CSA: 2.5mm²Wire Connection Method: ScrewRated Current: 24ARated Voltage: 600VBlock Orientation: Through Hole Right AngleProduct Range: -
