Hard Disk Summary
-------------------
Hard Disk Model ID . . . . . . . . . . . . . . . : WDC WD10EADS-22M2B0
Firmware Revision . . . . . . . . . . . . . . . : 01.00A01
Hard Disk Serial Number . . . . . . . . . . . . : WD-WCAV58648205
Total Size . . . . . . . . . . . . . . . . . . . : 953867 MB
Power On Time . . . . . . . . . . . . . . . . . : 626 days, 18 hours
Estimated Remaining Lifetime . . . . . . . . . . : 766 days
Health . . . . . . . . . . . . . . . . . . . . . : 80 % (Good)
ATA Information
-----------------
Hard Disk Cylinders . . . . . . . . . . . . . . : 1938021
Hard Disk Heads . . . . . . . . . . . . . . . . : 16
Hard Disk Sectors . . . . . . . . . . . . . . . : 63
ATA Revision . . . . . . . . . . . . . . . . . . : ATA8-ACS
Transport Version . . . . . . . . . . . . . . . : SATA Rev 2.6
Total Sectors . . . . . . . . . . . . . . . . . : 1953525168
Bytes Per Sector . . . . . . . . . . . . . . . . : 512
Buffer Size . . . . . . . . . . . . . . . . . . : 32767 KB
Multiple Sectors . . . . . . . . . . . . . . . . : 16
Error Correction Bytes . . . . . . . . . . . . . : 50
Unformatted Capacity . . . . . . . . . . . . . . : 953870 MB
Maximum PIO Mode . . . . . . . . . . . . . . . . : 4
Maximum Multiword DMA Mode . . . . . . . . . . . : 2
Maximum UDMA Mode . . . . . . . . . . . . . . . : 300 MB/s (6)
Active UDMA Mode . . . . . . . . . . . . . . . . : 300 MB/s (4)
Minimum Multiword DMA Transfer Time . . . . . . : 120 ns
Recommended Multiword DMA Transfer Time . . . . : 120 ns
Minimum PIO Transfer Time Without IORDY . . . . : 120 ns
Minimum PIO Transfer Time With IORDY . . . . . . : 120 ns
S.M.A.R.T. Details
--------------------
Off-line Data Collection Status . . . . . . . . : Suspended By Interrupting Command From Host
Self Test Execution Status . . . . . . . . . . . : Successfully Completed
Total Time To Complete Off-line Data Collection : 20760 seconds
Security Mode
---------------
Security Mode . . . . . . . . . . . . . . . . . : Supported
Security Erase . . . . . . . . . . . . . . . . . : Supported
Security Erase Time . . . . . . . . . . . . . . : 212 minutes
Security Enhanced Erase Feature . . . . . . . . : Supported
Security Enhanced Erase Time . . . . . . . . . . : 212 minutes
Serial ATA Features
---------------------
S-ATA Compliance . . . . . . . . . . . . . . . . : Yes
S-ATA I Signaling Speed (1.5 Gps) . . . . . . . : Supported
S-ATA II Signaling Speed (3 Gps) . . . . . . . . : Supported
Receipt Of Power Management Requests From Host . : Supported
PHY Event Counters . . . . . . . . . . . . . . . : Supported
DMA Setup Auto-Activate Optimization . . . . . . : Supported, Disabled
Software Settings Preservation . . . . . . . . . : Supported, Enabled
Native Command Queuing (NCQ) . . . . . . . . . . : Supported
Queue Length . . . . . . . . . . . . . . . . . . : 32
Disk Information
------------------
Disk Family . . . . . . . . . . . . . . . . . . : Caviar Green
Form Factor . . . . . . . . . . . . . . . . . . : 3.5"
Capacity . . . . . . . . . . . . . . . . . . . . : 1 TB (1 x 1 000 000 000 000 bytes)
Number Of Disks . . . . . . . . . . . . . . . . : 2
Number Of Heads . . . . . . . . . . . . . . . . : 4
Disk Interface . . . . . . . . . . . . . . . . . : Serial-ATA/300
Buffer-Host Max. Rate . . . . . . . . . . . . . : 300 MB/seconds
Buffer Size . . . . . . . . . . . . . . . . . . : 32768 KB
Drive Ready Time (Typical) . . . . . . . . . . . : 14.3 seconds
Average Seek Time . . . . . . . . . . . . . . . : ? ms
Track To Track Seek Time . . . . . . . . . . . . : ? ms
Full Stroke Seek Time . . . . . . . . . . . . . : ? ms
Width . . . . . . . . . . . . . . . . . . . . . : 101,6 mm (4,0 inch)
Depth . . . . . . . . . . . . . . . . . . . . . : 147,0 mm (5,8 inch)
Height . . . . . . . . . . . . . . . . . . . . . : 26,1 mm (1,0 inch)
Weight . . . . . . . . . . . . . . . . . . . . . : 630 grams (1,4 pounds)
Acoustic (Idle) . . . . . . . . . . . . . . . . : 2,4 Bel
Acoustic (Min Performance And Volume) . . . . . : 2,5 Bel
Acoustic (Max Performance And Volume) . . . . . : 2,9 Bel
Required Power For Spinup . . . . . . . . . . . : 1 671 mA
Power Required (Seek) . . . . . . . . . . . . . : 5,4 W
Power Required (Idle) . . . . . . . . . . . . . : 2,8 W
Power Required (Standby) . . . . . . . . . . . . : 0,4 W
Manufacturer . . . . . . . . . . . . . . . . . . : Western Digital Corporation
Manufacturer Website . . . . . . . . . . . . . . : http://www.westerndigital.com/en/products
S.M.A.R.T.
------------
No. Attribute Thre.. Value Worst Data Status Flags
1 Raw Read Error Rate 51 200 200 000000000000 OK Self Preserving, Error-Rate, Performance, Statistica..
3 Spin Up Time 21 117 108 000000001BEE OK Self Preserving, Performance, Statistical, Critical
4 Start/Stop Count 0 94 94 00000000177F OK (Always passing) Self Preserving, Event Count, Statistical
5 Reallocated Sectors Co.. 140 200 200 000000000000 OK Self Preserving, Event Count, Statistical, Critical
7 Seek Error Rate 0 200 200 000000000000 OK (Always passing) Self Preserving, Error-Rate, Performance, Statistical
9 Power On Time Count 0 80 80 000000003AC2 OK (Always passing) Self Preserving, Event Count, Statistical
10 Spin Retry Count 0 100 100 000000000000 OK (Always passing) Self Preserving, Event Count, Statistical
11 Drive Calibration Retr.. 0 100 100 000000000000 OK (Always passing) Self Preserving, Event Count, Statistical
12 Drive Power Cycle Count 0 100 100 000000000360 OK (Always passing) Self Preserving, Event Count, Statistical
192 Power off Retract Cycl.. 0 200 200 00000000015E OK (Always passing) Self Preserving, Event Count, Statistical
193 Load/Unload Cycle Count 0 190 190 000000007FE9 OK (Always passing) Self Preserving, Event Count, Statistical
194 Disk Temperature 0 121 100 00000000001A OK (Always passing) Self Preserving, Statistical
196 Reallocation Event Count 0 200 200 000000000000 OK (Always passing) Self Preserving, Event Count, Statistical
197 Current Pending Sector.. 0 200 200 00000000000D OK (Always passing) Self Preserving, Event Count, Statistical
198 Off-Line Uncorrectable.. 0 200 200 00000000000D OK (Always passing) Self Preserving, Event Count
199 Ultra ATA CRC Error Co.. 0 200 200 000000000000 OK (Always passing) Self Preserving, Event Count, Statistical
200 Write Error Rate 0 200 200 000000000005 OK (Always passing) Error-Rate
