Eliptical Waveguides
Full Range Models Feature A 90 X 60 Elliptical Waveguide
In Real-World Terms This Means That The Higher Frequencies Can Be Heard With Definition At 90 In The Horizontal Plane, And 60 In The Vertical.
All Full Range Models In The Evp-X Mkii Series Use This Same Elliptical Waveguide Design Which Makes For Controllable Coverage When Using Multiple Evo-X Series Loudspeakers.
Tough Carpet
Each Evp-X Mkii Pa Speaker And Subwoofer Is Protected By A Durable Carpet Covering And Steel Grille.
The Mkii Version Features A 4-Way Carry Handle And A Dual Angle Pole Mount Making It Both Portable And Versatile For Varying Installation Applications, Ensuring The Hf Sound Is Directed Straight At Your Audience.
Configuration | 2-Way |
Frequency Response (+/- 3dB) | 45 -20kHz |
Power (RMS / Program / Peak) | 300W / 600W / 1200W |
Impedance | 8 |
Max SPL | 129 dB |
Low Frequency Transducer | 15 |
High Frequency Transducer | 1.75 Titanium Compression Driver |
Nominal Coverage | 90 x 60 |
Waveguide Type | Elliptical |
Input | 2 x Speakon / Thru, 2 x 6.3mm jack |
Net Weight | 23.4kg |
Gross Weight | 29.5kg |
Dimensions | 645mm x 445mm x 445mm |
Key Features
|
|
