Specifications:
CPU: ESP32-D0WD-V3, Xtensa dual-core 32-bit LX6 microprocessor
Main Frequency: 240MHz (max)
Memory: 448KB ROM+520KB SRAM+16KB RTC SRAM+4MB external QSPI Flash
WIFI: 2.4GHz, 802.11b/g/n mode
Bt: Bt V4.2 BR/EDR and Bt LE standards
Operating Voltage: DC 3.0-3.6V
Operating temperature: -40~85°C
Liquid crystal screen parameters
Screen size: 2.8 inch
Screen type: TN TFT Resistive touch screen
Resolution: 240x320(pixels)
Effective display area: 45.20(W)x59.45(H)(mm)
Operating Temperature: -10~60
Storage Temperature: -20~70
Features:
1. Supports external speakers, plays audio, comes with RGB three color indicator lights, and has rich indicator states.
2. Comes with a resistive touch screen for convenient human-computer interaction. Provide rich example programs for easy learning.
3. Stand
