Description:
1. Working voltage DC 12V
2. Standby current (all relays closed) 12MA, 1 relay open 40MA, 2 relays open 69MA, 3 relays open 95MA,4 relays open 122MA,5 relays open 149MA,6 relays open 174MA, 7 relays open 198MA,8 relays open 225MA
3. Enhanced RS485 interface protection (TVS)
4. ''open'' ''close'' ''Momentary'' ''Self-locking'' ''Interlock'' ''Delay'' 6 Commands
5. MODBUS RTU command, Support 03 06 16 function code
6. Under the ''Delay'' command ,the maximum delay is 255 seconds;
7. MODBUS commands can be made serial HyperTerminal (serial assistant) OR ''Modbus Poll'' Enter;
8. Under the MODBUS command mode, it can support up to 64 devices in parallel
9. The default baud rate is 9600BPS. The baud rate can be selected through jumpers: 2400 4800 9600 19200BPS
10. Size: 145*90*40mm
