Application area:
-Suitable for steel and especially for stainless steel
-Particularly effective at cutting thin-walled pipes and profiles, thin metal sheets, bodywork panels etc.
Very good cutting performance with a long service life
-Very fast cutting times
-Extremely thin for precise, almost burr- and chatter-free cuts (very clean and cool cutting surfaces)
-Very easy to use and ensures user- and machine-friendly working
-Very good breakage resistance
Technical information:
Versatility (points system) - 2 of 4 points
Service life (points system) - 3 of 4 points
Handling/user-friendliness (point system) - 3 of 4 points
Cutting ability (point system) - 4 of 4 points
Cut quality (point system) - 3 of 4 points
Diameter - 115mm
Thickness - 1mm
Drill hole - 22.23 rpm
Design - Straight
Max. rotation speed - 13300rpm
Max. circumferential speed - 80 m/s
Notice:
-Storage: dry, at 20C ambient temperature
-Work only with appropriate protective clothing
-Always use an appropriate protective cover when performing cutting work
-Only use undamaged discs
-Do not jam/tilt the discs during cutting - increased risk of breakage!
-Ensure proper contact pressure
-Always clamp cutting discs (straight design) with metal ring towards the machine
-For further information, please refer to the package insert
