XF0165-4 SC/APC - LC/UPC Simplex Single Mode Fiber Optic Patch Cord 2.0mm 15M

-These 2.0 mm diameter patch cords are built using ITU-T G657.A2 bend-insensitive optical fibers, featuring SC connectors on one end and LC connectors on the opposite end.

-Insertion Loss (per IEC 61300-3-4, Method B): 0.30 dB

-Return Loss (as defined by IEC 61300-3-6, Method B): 50 dB (UPC), 60 dB (APC)

-Mechanical Durability: Typically <0.1 dB variation after 500+ connection cycles

-Flammability Rating: Compliant with UL94 V-0 standards

-Temperature Range: Operates reliably between -40°C and +85°C

-End-Face Geometry: Manufactured to meet IEC 61755-3 specifications

-LC Connector Standards: Meets IEC 61754-20, TIA 604-10-A, and RoHS directives

-SC Connector Standards: Conforms to IEC 61754-4, TIA 604-3, and RoHS requirements

-FC Connector Standards: Per IEC 61754-13, TIA 604-4-A, and RoHS compliance

-ST Connector Standards: Built to IEC 61754-2, TIA 604-2, and RoHS specifications

-LSH Connector Standards: Aligns with IEC 61754-15, TIA 604-16, and RoHS compliance

Package Weight: 55g

Package Dimensions: 18cm x 18cm x 2cm

Package Includes:

1 x Simplex Single Mode Fiber Optic Patch Cord 15M
