Module nature: Non-isolated boost
Rectification: Ssynchronous rectification
Input voltage: Limit 3V-40V, recommended value 3.0-35V
Output voltage: Limit 5.0V-45V; The recommended value is 5V-40V. Output voltage continuously adjustable (increasing voltage of potentiometer in clockwise direction)
Input current: Limit 0-5A, recommended value 0-3A
Conversion efficiency: Up to 94
Switching frequency: 220KHz, second generation switching power technology
Operating temperature range : -40~ + 150, recommended value :-20~ + 85
Full load temperature rise :<40
Output ripple : < 100mV
Load regulation : 0.5
Voltage regulation : 0.5
Short circuit protection: output current limiting protection, automatic recovery.
Reverse polarity protection: reverse input 40V protection
Module interface:
Connection by terminal input or output power
IN +: positive input
- : - input
Output +: positive output
- : negative output
Module size:
Size : 55 x 28 x 15mm
Fixing screw :3.0mm x 4, hole center is 3.5mm away from plate edge
