Printing | ||
Printingmethod | Directthermal | |
Resolution | 203DPI | |
Printwidth | 80mm | |
Printingspeed | MAX:127mm/s¿MIN:50.8mm/s | |
Memory | DRAM:4M FLASH:4M | |
Printheadtemperaturesensor | Thermalsensitiveresistance | |
Paperexistsdetection | Photosensor | |
Interface | USB | |
Charactersize | ANK¿Font A¿1.5×3.0mm¿12×24 dots¿ Font B¿1.1×2.1mm¿9×17 dots¿ Chinese,traditionalChinese:3.0×3.0mm¿24×24 dots¿ | |
BarcodeCharacter | ||
Barcode | CODE128¿EAN128¿ITF¿CODE39¿CODE93¿EAN13¿EAN13+2¿EAN13+5¿EAN8¿EAN8+2¿EAN8+5¿CODABAR¿POSTNET¿UPC-A¿UPCA+2¿UPCA+5¿UPC-E¿UPCE+2¿UPC-E+5¿CPOST¿MSI¿MSIC¿PLESSEY¿ITF14¿EAN14 | |
Internalfont | FONT0toFONT8 | |
Enlargement&rotation | ¿0°¿90°¿270°¿360°¿1to10timesenlargementinbothdirection;0°¿90°¿270°¿360°rotation | |
Image | MonochromaticPCX,BMPimagefilescanbeloadtoFLASH,DRAM | |
Mediatype | ||
Papertype | Paperroll,sticker,adhesive sticker,etc | |
Paperwidth | 20mm¿82mm | |
Rollexternaldiameter | MAX100mm | |
Rollinnerdiameter | MIN25mm | |
Paperofftype | Peeloff | |
Power | ||
Powersupplyinput | 24VDC,2.5A | |
Physicalcharacteristics | ||
Weight | 1.42KG | |
Dimensions | 212.4(D) x 143(W) x 145.5(H)mm | |
EnvironmentalRequirements | ||
Workenvironment | 5¿45¿,20¿80%RH(nocondensation) | |
Storageenvironment | ¿40¿55¿¿¿93%RH¿40¿¿ |
