Yagi 1990-2170 MHz Antenna For 3G huawei modem - TS9
10M cable outdoor
1990-2170 MHz 12DBi 3G Yagi Antenna For ZTE / Novatel / sierra wireless modems + 10m cable N male to TS9
Description:
Product Name GSM Yagi Antennas
Electrical specifications
Frequency Range-MHz 1990-2170MHz
VSWR ≤1.5
Input Impedance-Ω 50
Gain-dBi 12
Polarization Vertical
F/B ratio-dB
Horizontal Beamwidth - 54/48/40/36/30
Vertical Beamwidth - 48/40/36/32/30
Maximum Power -W 50
Bandwidth-MHz 100
Connector N-F
Mechanical Specifications
Dimensions-mm
Weight-kg 0.3
Length-cm 46.3
Mounting Mast Diameter-mm
50-100
Other
Package including:
1 X Mounting Mast Clamp
1 X 12DBi GSM Yagi Antenna
1 X 3M N plug to TS9 plug right angle pigtail RG316
