http://usa.yamaha.com/products/audio-visual/aventage/rx-a820_black_u/
| Amplifier Section | Channel | 7.2 |
|---|---|---|
| Rated Output Power (1kHz, 2ch driven) | 110 W (8 ohms, 0.9% THD) | |
| Rated Output Power (20Hz-20kHz, 2ch driven) | 100 W (8 ohms, 0.09% THD) | |
| Dynamic Power per Channel (8/6/4/2 ohms) | 140 / 180 / 210 / 250 W | |
| Surround Sound Processing | CINEMA DSP | Yes (3D) |
| DSP Programs | 17 | |
| Virtual Presence Speaker | Yes | |
| Dialogue Lift | Yes (No presence speakers required) | |
| SILENT CINEMA / Virtual CINEMA DSP | Yes | |
| Dolby TrueHD | Yes | |
| Dolby Digital Plus | Yes | |
| Dolby Pro Logic IIx | Yes | |
| DTS-HD Master Audio | Yes | |
| Dialog Level Adjustment | Yes | |
| Audio Features | Pure Direct | Yes (With video on mode) |
| Compressed Music Enhancer | Yes | |
| YPAO multi-point measurement | Yes (R.S.C. w/multi-point measurement) | |
| Adaptive DRC (Dynamic Range Control) | Yes | |
| Initial Volume & Maximum Volume Setting | Yes | |
| A.R.T. Wedge | Yes | |
| Bi-amp capability | Yes | |
| Audio Delay | Yes (0-500 ms) | |
| 192kHz/24-bit DACs for all channels | Yes (Burr-Brown) | |
| Video Features | HDMI 3D pass-through | Yes |
| HDMI Audio Return Channel | Yes | |
| Component upscaling | Yes (480i) | |
| HDMI upscaling | Yes (Analog to HDMI/HDMI to HDMI) | |
| Deep Color/x.v.Color/24Hz Refresh Rate /Auto Lip-Sync | Yes | |
| 4K Ultra HD Pass-through and upscaling | Yes | |
| Extensive Connection | HDMI Input/Output | 8 (1 front ) / 2 (Simultaneous) |
| HDMI CEC | Yes (SCENE, device control) | |
| USB Input | iPod®/iPhone®/iPad®, USB memory, portable audio player (MP3, WMA, AAC up to 48 kHz / 16-bit, FLAC/WAV up to 96 kHz / 24-bit) | |
| Network Port | Yes (AirPlay, Pandora®, Rhapsody®, SiriusXM Internet Radio, DLNA® 1.5, vTuner) | |
| Front AV Input | HDMI, USB, analog audio, optical, composite | |
| Digital Audio Input/Output: Optical | 2 / 0 | |
| Digital Audio Input/Output: Coaxial | 2 / 0 | |
| Analog Audio Input/Output | 5 / 1 | |
| Component Video Input/Output | 2 / 1 | |
| Composite Video Input/Output | 5 (1 front) / 1 | |
| Preout | 7.2 channel | |
| Headphone Output | Yes | |
| Connectivity | AirPlay | Yes |
| DC Out | Yes (USB DC output 5 V / 0.5 amp) | |
| Tuner Section | FM/AM Tuner | Yes |
| User Interface | On-screen display | Graphical user interface |
| SCENE | Yes (Four sets) | |
| App Control | Yes (iPhone/iPad, Android™ phone/tablet, Kindle Fire™) | |
| Web Browser Control | Yes | |
| Remote Control Unit | Yes (Preset) | |
| Zone Control | Zone 2 Audio Output | Line output |
| Powered Zone | Zone 2 | |
| RS-232C Interface | Yes | |
| +12V Trigger Output | Yes | |
| Remote (IR) Input/Output | 1 / 1 | |
| Zone B Output | Yes (HDMI) | |
| General | Standby Power Consumption (IR only) | ≤0.1 W |
| Auto Power Standby | Yes | |
| Dimensions (W x H x D) | 17-1/8” x 6-3/4” x 14-1/2” | |
| Weight | 23.8 lbs. | |
| ECO mode | Yes |
| Detachable Power Cord | Yes | |
|---|---|---|
| Front Panel | Aluminum | |
