Specifications
Interface | PCI 2.2 (Low-Profile PCI compatible) | |
MPEG Encoder | Capture Resolution | DVD (720x480-NTSC, 720x576-PAL) MPEG2 (720x480 / 640x480 / 480x480 / 352x480 – NTSC)(720x576 / 640x576 / 480x576 / 352x576 – PAL) SVCD (480x480-NTSC, 480x576-PAL)VCD (352x240-NTSC, 352x288-PAL) MPEG1 (352x240-NTSC, 352x288-PAL) |
Video bit rate | DVD:1~9 Mbit/sec (CBR, VBR) MPEG2:1~15 Mbit/sec (CBR, VBR) SVCD:2~2.5 Mbit/sec (CBR) VCD:1.15 Mbit/sec (CBR) MPEG1: 0.5~8 Mbit/sec (CBR) *CBR= Constant Bit Rate, *VBR= Variable Bit Rate | |
Audio bit rate | 192 / 224 / 384 Kbit/sec | |
Audio sample Rate | 32 / 44.1 / 48 KHz | |
Input | Video | Composite video in- RCA jackS video in – Mini Din connector |
Audio | Stereo Audio In- Phone Jack | |
TV Tuner | TV Channel | CATVUHF/VHF |
RF Input | Coaxial RF | |
TV Stereo/SAP Sound | BTSC, EIAJ, NICAM, or A2 | |
Remote | Remote Control | Infrared Remote Control (optional) |
Dimension | Encoder Card | 120(W) x 65(H) mm |
System Requirements
In order to install and use PG600-2 successfully, your system must satisfy with following requirements.
