Performance
| Product colour | Black |
|---|---|
| International Protection (IP) code | IP52 |
| Certification | EN 50581:2012, RoHS 2011/65/EU (2015/863) - EN 50581:2012, IEC 63000, REACH 1907/2006, IEC 62368-1 2nd ed. EN 62368-1:2014/AC:2015, UL/IEC 60950-1, 2nd ed. CAN/CSA C22.2 No.60950-1, 2nd ed. IEC 62471:2006 (Ed.1.0), EN 62471:2008 (LED), FCC 47 CFR Part 15B, ICES-003, EN55032, EN55024, EN55035, VCCI, and SABS |
Design
| Product colour | Black |
|---|
Ports & interfaces
| Connectivity technology | Wired |
|---|---|
| Standard interfaces | RS-232,RS-485,Keyboard wedge,USB |
| Standard interfaces | RS-232,USB |
Weight & dimensions
| Width | 86 |
|---|---|
| Weight | 318 |
| Height | 145 |
| Depth | 83 |
Operational conditions
| Operating temperature (T-T) | 0 - 50 |
|---|---|
| Operating relative humidity (H-H) | 5 - 95 |
| Storage temperature (T-T) | -40 - 70 |
Scanning
| Scanner type | 1D/2D |
|---|---|
| Sensor type | LED |
| Type | Fixed bar code reader |
| Pitch reading angle | -60 - 60 |
| Optical sensor resolution (W x H) | 1280 x 800 |
| 2D (matrix & stacked) barcodes supported | Aztec Code,Composite Codes,Data Matrix,Dot Code A,Han Xin,MaxiCode,Micro QR Code,MicroPDF417,PDF417,QR Code,TLC-39 |
| Working distance | 660 |
| Light levels (direct sunlight) | 0 - 107700 |
| Linear (1D) barcodes supported | Codabar,Code 11,Code 128,Code 39,Code 93,EAN-13,GS1 DataBar,MSI,U.P.C. |
Logistics data
| Harmonized System (HS) code | 84716070 |
|---|
Power
| Input voltage | 5.5 |
|---|---|
| Power source type | RS-232,USB |
