Packaging data
| Quantity per pack | 1 |
|---|
Ports & interfaces
| USB 2.0 ports quantity | 1 |
|---|---|
| Connectivity technology | Wired |
| Bluetooth | N |
| USB port | Y |
| Ethernet LAN | N |
| Wi-Fi | N |
Design
| Product colour | Black |
|---|---|
| Display | N |
Power
| AC input voltage | 100 - 240 |
|---|---|
| AC input frequency | 50 - 60 |
Packaging content
| Cables included | AC |
|---|
Weight & dimensions
| Width | 197 |
|---|---|
| Weight | 1100 |
| Depth | 267 |
| Height | 191 |
Features
| Quantity | 1 |
|---|
Operational conditions
| Operating relative humidity (H-H) | 10 - 90 |
|---|---|
| Storage relative humidity (H-H) | 5 - 95 |
| Storage temperature (T-T) | -40 - 60 |
| Operating temperature (T-T) | 4.4 - 41 |
Printing
| Print technology | Thermal transfer |
|---|---|
| Maximum resolution | 203 x 203 |
| Print speed | 152 |
| Maximum printing width | 104 |
| Colour | N |
Paper handling
| Maximum roll diameter | 127 |
|---|---|
| Core diameter | 12.7 |
| Maximum label length | 0.991 |
| Ribbon length | 300 |
| Media thickness | 0.08 - 0.1905 |
| Ribbon width | 109.2 |
| Maximum label width | 112 |
| Supported paper width | 25.4 - 112 |
Performance
| Internal memory | 128 |
|---|---|
| Flash memory | 256 |
| Page description languages | EZPL,XML,ZPL II |
| Built-in barcodes | 1D,2D,AZTECCODE,CODABAR (NW-7),Code 11,Code 128 (A/B/C),Code 39,Code 49,Code 93,Data Matrix,EAN13,EAN8,Industrial 2/5,Interleaved 2/5,MaxiCode,PDF417,POSTNET,QR Code,UPC-A,UPC-E |
| Number of fonts | 23 |
| Certification | IEC 60950-1, EN55022 Class B, EN55024, EN61000-3-2, EN61000-3-3, FCC Class B, ICES-003, FCC 15.209; 15.247(d), IC RSS 247, EN 300 328, EN 301 893, EN 62311, cTUVus, CE Marking, VCCI, C-Tick, S-Mark, CCC, CU, BSMI, KCC, SABS, IN-Metro, BIS, NOM |
Logistics data
| Harmonized System (HS) code | 84433210 |
|---|
