ZTE MC801A is a 5G Indoor WiFi router supporting the latest Wi-Fi 6 access technology, allowing multiple users to access the 5G network at the same time. ZTE 5G Indoor CPE MC801A supports both NSA & SA 5G Networks, compatible with mainstream 4G and 5G standards. The device enables consumers to enjoy the advantages of ultra-fast 5G networks and 5G services, including immersive streaming, gaming and entertainment experience through virtual reality, augmented reality and 3D technologies.
Specifications:
Category: 5G Router
Communication Standard: 3GPP Release 15
Chipset: Qualcomm 5G SDX55M
CPU: Cortex A7 up to 1.4GHz
Supported networks
Network technology: 5G NR, 3GPP Rel 15 5G NR SA & NSA option 3X
Network frequencies: 5G: 41/77/78/79
Support 4G LTE Band: 1/3/7/20/28/40 and 3G WCDMA Band: 1/8
Data rate speeds
5G: DL: 3.8 Gbit/s and UL: 542 Mbit/s
LTE Category: 22 (DL: 2.4 Gbit/s and UL: 316 Mbit/s), 5CA, MIMO 4x4 for B1/3/7
WCDMA: DC (up to 42Mbit/s)
Modulation: DL 256QAM, UL 64QAM
Wi-Fi: 802: 11a/b/g/n/ac/ax(WiFi 6), dual-band, 4 x 4 MIMO
WiFi 5GHz: up to 80MHz, 2 x 2 MIMO, up to 1.2Gb/s
WiFi 2.4GHz: up to 40MHz, 2 x 2 MIMO, up to 575Mb/s
WLAN encryption standards: WPA, WPA2, WPS
Support up to 30 WiFi users simultaneously
Functions: Blocklist, 3 SSIDs (2 Primary, 1 Guest)
Interface
SIM card slot: (NANO SIM) x 1
Tel port: (RJ11) x 1 (CSFB)
WAN/LAN GE port x 1
1GE port(RJ45) x 1
DC port x 1
The ZTE Model MC801A is a 5G indoor Wi-Fi router designed for ultra-fast internet speeds and home Wi-Fi coverage. It supports both 5G NSA and SA networks, allowing multiple devices to access the 5G network simultaneously. The device also supports 4G LTE and 3G WCDMA networks.
Key features and specifications:
5G Technology: Supports 5G NR (SA and NSA) with theoretical downlink speeds up to 4.6 Gbps.
Wi-Fi 6 (802.11ax): Provides fast and reliable Wi-Fi speeds for multiple devices.
Qualcomm Snapdragon X55 Chipset: Enables high-speed data transmission and efficient network performance.
Dual-Band Wi-Fi: Supports 2.4 GHz and 5 GHz Wi-Fi bands for optimal network coverage.
Antennas: Features both 5G/LTE main and diversity antennas (included).
Ports: 1 x Power Adaptor Port, 2 x LAN Ports (RJ45), 1 x Tel Port (RJ11), 2 x External LTE Antenna Ports (Connection Type: TS-9).
Sim Card Slot: 1 x Nano-SIM card slot.
Additional Features: Supports ZTELink app, Router Placement Assistant, and Wi-Fi Optimization (Auto Channel Selection).
