2-700M 3W HF FM VHF UHF FM Transmitter Broadband RF Power Amplifier Short Wave Amplifier

20 available / new

R439.00

Add to watchlist Watch

Shipping

R35.00 Standard shipping using one of our trusted couriers applies to most areas in South Africa. Some areas may attract a R30.00 surcharge. This will be calculated at checkout if applicable.
Check my rate

The seller has indicated that they will usually have this item ready to ship within 12 business days. Shipping time depends on your delivery address. The most accurate delivery time will be calculated at checkout, but in general, the following shipping times apply:

Standard Delivery

Main centres:	1-3 business days
Regional areas:	3-4 business days
Remote areas:	3-5 business days

Seller

szulou3466

93.40 % Positive ratings

Buyer protection

How you're covered

Returns

Replacement Guarantee: 7 Days: We stand by this guarantee

Get it now, pay later

Product details

Condition

New

Location

International

Bob Shop ID

641105141

Application: Broadband RF power amplification, suitable for HF FM VHF UHF FM transmission of various radio applications, short-wave FM remote control toys, radio walkie-talkies, digital radio stations, etc., can output up to 3 watts, 15V voltage supply, 2MHZ to 700MHZ can work frequency range. Technical indicators: 1. Supply voltage: DC + 12 ~ 15V (typical 15V @ 0.3-0.5A) pad interface 2. Working frequency: 2MHZ-700MHZ, input and output impedance: SMA@50 ohm; 3. Maximum output power: 34.8dbm (3W) 4. Typical power gain: 35 dB (>300M gain slightly decreased) 5. Maximum input power: <+10dBm 6. Module size: 46 x 32 x 15mm (length * width * height) Measured power indicator: 2-300M: +34dBm max 3W 300-500M: >+32dBm

Package includes:

1 xRF Amplifier
