4 Ports 18650 Battery Capacity Type-C Tester Module MAh MWh

4 Channel Battery Tester Parameters:

Operating voltage: DC5V Applicable battery: Meet the stop discharge voltage 2.5 ~ 3.5V, 2.8V start ~ 4.2V full battery are applicable Power supply interface: two Type-C power supply interface System language: English / Chinese switchable Test quantity: 4-channel charging and discharging measurement Internal resistance measurement: support, using the DC two-wire method to test the internal resistance Charging function: support, full automatic cut off charging (does not support charging of lithium iron phosphate batteries) Discharge function: support, automatically stop when conditions are met, discharge current is not adjustable Automatic charging and discharging: support, automatic mode ends when the battery is fully charged Cycle charging and discharging: support, 1~9 cycles adjustable (only automatic mode support) Status alert: support Heat dissipation mode: fan active heat dissipation Overheat protection: Support Stop discharge voltage: 2.5V, 2.6V, 2.7V, 2.8V, 2.9V, 3.0V, 3.1V, 3.2V, 3.3V, 3.4V, 3.5V, a total of 11 grades adjustable Discharge current: maximum about 1A current, not adjustable, does not support independent transformation Charging voltage: special battery charging chip control, maximum of about 1A charging, full charge voltage 4.2V Power failure save: only save the setting parameters, not save the measurement data Product size: 150×103×36mm Package size: 182×112×50mm
