Amphenol Communications (MUSBA31130) USB Connector, USB Type A, USB 2.0

USB Connector, USB Type A, USB 2.0, Receptacle, 4 Ways, Through Hole Mount,Right AngleProduct OverviewThe MUSBA31130 is a 4-position rugged USB Connector with gold-plated over nickelcontacts, standard A series receptacle type per USB 2.0, right angle on PCB withright angle matching USB type connector termination style and UL94V-0 ratedblack engineering thermoplastic insulator housing. This connector meets militaryshock and vibration levels and IP67 per IEC 60529 in mated and unmatedconditions. The connector system is designed to provide a standard USB interfacefor enclosures exposed to harsh environments. Connectors mate with any standardUSB 2.0 plug. Achieves data rates up to 480Mb/s (USB 2.0).Nickel-plated die-cast zinc alloy shellWith rear shield, unified thread1.5A Current rating per contact30mR Maximum contact resistance1000MR Minimum insulation resistance-40 to +105°C Operating temperature rangeApplicationsMedical, Sensing & Instrumentation, Aerospace, Defence, Military, RFCommunications, Computers & Computer Peripherals, Test & Measurement,Communications & Networking, Consumer Electronics, Industrial, AudioProduct InformationUSB Connector Type: USB Type AUSB Standard: USB 2.0Gender: ReceptacleConnector Mounting: Through Hole MountOrientation: Right AngleContact Material: Phosphor BronzeContact Plating: Gold Plated ContactsProduct Range: MUSB
