Arcol (ACS5SR1J) Through Hole Resistor, Silicone Coated, 0.1 ohm

Through Hole Resistor, Silicone Coated, 0.1 ohm, ACS, 5 W, ± 5%, Axial Leaded,157 VProduct InformationResistance: 0.1ohmProduct Range: ACSPower Rating: 5WResistance Tolerance: ± 5%Resistor Case / Package: Axial LeadedVoltage Rating: 157VResistor Element Type: WirewoundTemperature Coefficient: ± 90ppm/°CAutomotive Qualification Standard: -Product OverviewThe ACS5S series from Arcol/Ohmite are silicone coated axial leaded resistors.Design of the ACS resistor provides a good balance of power density, stabilityand resistance to environment for a broad range of industrial power applicationssuch as drives and controls. Resistance range include E24 and E12 decade values(for values >10K).Inductive resistance range of 0.05ohm to 22Kohm & non inductive resistance rangeof 0.05ohm to 2KohmBody diameter is 4.78mm (±0.8) and 0.8mm (±0.02) drill hole35mm (±1) lead length and 12.7mm (±1.5) body lengthOperating temperature range from -55°C to 275°CGood ratio between power capability and physical sizeWound to maximise high pulse capability, low inductive versions availableTemperature coefficient of resistance wire is ±20ppmAvailable with ±1%, ±5% tolerance valuesInsulation resistance of 1000Mohm (> 100V) and dielectric withstand voltage is500VContinuous working voltage is 157V and rated power is 5W
