Electrical Specification (Function of the Performance):
Operating Speed (at no load):
6.0V | 0.13 sec/60°
8.4V | 0.09 sec/60°
Running Current (at no load):
6.0V | 350mA Max
8.4V | 400mA Max
Stall Torque:
6.0V | 3.4kg.cm Max
8.4V | 4.7kg.cm Max
Maximum Current:
6.0V | 1.0A Max
8.4V | 1.3A Max
Idle Current:
6.0V | 9.5mA
8.4V | 9.5mA
Mechanical Specification:
Overall Dimensions: See Drawing Below
Weight: 20.5+0.5 g
Connector Wire Gauge: JR
Connector Wire Length: 240±8mm (W/O Connector)
Output Gear Spline: 23T
Bearing: 2BB
Gear Type: Metal
Extreme Angle: 360°
Control Specification:
Control System: PWM
Operating Travel: 90° ±8°( when 1000-2000 sec )
Neutral Position: 1500 u sec
Rotating Direction: Counter Clockwise / Pulse Traveling 1500 to 1900 sec
Pulse Width Range: 500-2500 sec
