Specifications:
Housing Material: ABS
Dimensions: 58.7mm x 91.3mm x 17.1mm (excluding protruding parts)
Frequency Accuracy: <2ppm
Frequency Stability: <1ppm
Display: 2.8-inch TFT (320 x 240) resistive touchscreen
USB Interface: Type-C, CDC (serial communication mode)
Power Source: USB 5V, 150mA; internal 650mAh battery with max charging current of 300mA. Charging time: 1-2 hours
Low Input Mode:
Frequency Range: 100kHz—350MHz
Input Attenuation: Manual and automatic; 0dB—31dB, adjustable in 1dB steps
Maximum Input Level: +10dBm with no attenuation; damage occurs at +20dBm
Minimum Detectable Signal: -102dBm @ 30kHz RBW
Phase Noise: -90dB/Hz @ 100kHz offsets; -115dB/Hz @ 1MHz offsets
Resolution Bandwidth Options: 3, 10, 30, 100, 300, 600kHz, with auto-selection available
High Input Mode:
Frequency Range: 240MHz—960MHz
Imped
