BOSS FZ-1W ALL ORIGINAL, WAZACRAFT, MADE IN JAPAN, SILICON TRANSISTOR BASED FUZZ CIRCUIT WITH VINTAG

Features

    Premium Waza Craft pedal for the ultimate BOSS tone experience
    Redefined fuzz sounds that combine classic tone and response with modern versatility and stability, realized through BOSS Waza innovation
    Vintage mode delivers a retro fuzz experience with aggressive tone, dynamic touch response, and extreme sensitivity to input volume
    Modern mode provides a fatter sound and more mid focus to suit a wider range of music styles
    Powerful Tone knob provides deep sound-shaping control tuned for each mode
    Consistent sound and reliable performance with silicon transistor circuitry
    High-quality buffer for clean and clear tone when bypassed
    BOSS five-year warranty

Specifications
Nominal Input Level
    -20 dBu
Input Impedance
    1 M ohms (Effect Off)
    22 k ohms (Effect On)
Nominal Output Level
    -20 dBu
Output Impedance
    1 k ohms
Recommended Load Impedance
    10 k ohms or greater
Controls
    Pedal switch
    Mode switch
    FUZZ knob
    TONE knob
    LEVEL knob
Indicator
    CHECK indicator (Serves also as battery check indicator)
Connectors
    INPUT jack: 1/4-inch phone type
    OUTPUT jack: 1/4-inch phone type
    DC IN jack
Power Supply
    Alkaline battery (9 V, 6LR61 or 6LF22) or Carbon-zinc battery (9 V, 6F22)
    AC adaptor (PSA series: sold separately)
Current Draw
    16 mA
Expected battery life under continuous use
    Alkaline: Approx. 33 hours
    Carbon: Approx. 14 hours
    *These figures will vary depending on the actual conditions of use.
Accessories
    Leaflet (USING THE UNIT SAFELY, IMPORTANT NOTES, and Information)
    Alkaline battery (9 V, 6LR61 or 6LF22)
Options (sold separately)
    AC adaptor: PSA series
Size and Weight
Width
    73 mm
    2-7/8 inches
Depth
    129 mm
    5-1/8 inches
Height
    59 mm
    2-3/8 inches
Weight (including battery)
    430 g
    1 lb
