Bourns (3214W-1-104E) Trimpot, Multi Turn, Cermet, Top Adjust, 100 kohm

Trimpot, Multi Turn, Cermet, Top Adjust, 100 kohm, Surface Mount, 5 TurnsProduct InformationTrack Resistance: 100kohmTrimpot Type: Multi TurnNo. of Turns: 5TurnsElement Material: CermetAdjustment Type: Top AdjustPower Rating: 250mWPotentiometer Mounting: Surface MountResistance Tolerance: ± 10%Temperature Coefficient: ± 100ppm/°CProduct Range: 3214Trimpot Shape / Size: 4 mm SquareResistor Case / Package: SMDProduct Length: 4.8mmProduct Width: 3.5mmProduct Height: 5.1mmOperating Temperature Min: -65°COperating Temperature Max: 150°CQualification: AEC-Q200Product OverviewThe Bourns Trimpot 3214 series are cermet, surface mount trimmingpotentiometers. These potentiometers are multi-turn which performs a variety ofcircuit adjustments in all types of electronic equipment. Typical applicationsare measuring linear distance, angle or rotation in production equipments.4mm square potentiometer meets EIA/EIAJ/IPC/VECI SMD standard trimmer footprintSide or top adjustment with lead screwSealed to withstand board wash processing5 turns and rotational life of 200 cyclesResistance value ranges from 10 ohm to 2MohmTolerance of ±10%Temperature coefficient is ±100ppm/°COperating temperature ranges from -65°C to +150°CPower rating is 0.25WPick and place centring design with flush adjustment
