Bridgelux (BXRC-27E2000-C-73) LED, Warm White, 80 CRI Rating, 22.1W

Product Information:COB Colour: Warm WhiteColor Rendering Index Max: 80Power Rating: 22.1WLuminous Flux @ Test: 2000lmForward Current @ Test: 630mAViewing Angle: 120°Forward Voltage VF Typ: 35VNominal CCT (K): 2700KCOB Length: -COB Width: -Opto Case Style: -Lumens / Watt @ Current Test: 147lm/WLight Emitting Surface: 13.2mmLens Type: -Lens Shape: Round with Flat TopHeight: 1.9mmProduct Range: Gen 7 Vero 13 ArrayProduct OverviewVero represents a revolutionary advancement in chip on board (COB) light sourcetechnology and innovation. Vero LED light sources simplify luminaire design andmanufacturing processes, improve light quality, and define a platform for futurefunctionality integration. Vero is available in four different light emittingsurface (LES) configurations and has been engineered to reliably operate over abroad current range, enabling new degrees of flexibility in luminaire designoptimization. Vero arrays deliver increased lumen density to enable improvedbeam control and precision lighting with 2 and 3 SDCM color control standard forclean and consistent uniform lighting.Efficacy of 155 lmW typicalVero 13 lumen output performance ranges from 522 to 7073 lumensBroad range of CCT options from 2700K to 6500KCRI options include; minimum 70, 80, and 902 and 3 SDCM color control for 2700K-4000K CCTReliable operation at up to 2X nominal drive currentRadial die pattern and improved lumen densityThermally isolated solder padsOnboard connector portTop side part number markings
