Cudy GS1005PTS1 4-port GbE PoE+ Unmanaged Network Switch with 1x GbE and 1x SFP Uplink Ports

A PoE rack-mountable 5-GbE, 1-SFP switch with a 120W power supply and a silent cooling system.

Features

• 4× GbE with 802.3at/af Mode A PoE
• 1× Uplink GbE + 1× Uplink SFP
• 120W Power Supply
• Default/VLAN/Extend Modes
• Watchdog under VLAN or Extend Modes
• Desktop, Rack-Mount
• Comply with IEEE 802.3, IEEE 802.3u,IEEE802.3ab,IEEE802.3z standards
• Port #1: 60 Watts Maximum Output
• Port #2 ~ #4: 30 Watts Maximum Output for one port
• Ethernet port 10/100/1000M rate auto adaptive
• Flow control mode: full-duplex adopts IEEE 802.3x standard, half-duplex adopts Back pressure standard
• Support Port Auto-flip (Auto MDI/MDIX)
• Panel indicators to monitor working status and help fault analysis
• One-key smart switch, supports VLAN, Default, Extend

Technical Specification

Product: Cudy GS1005PTS1 Network Switch

SFP Slots: 1x 1.25G

RJ45 Ports: 1x Gigabit

RJ45 PoE Ports: 4x Gigabit

Physical Buttons: VLAN / Default / Extend DIP Switch

Max Power on a Single PoE Port:

• Port 1: 60W
• Port 2 ~ 4: 30W

PoE Port Notes: PoE port #1 supports 802.3at 60W output, and the rest support 30W 802.3at/af standards.

Extend Mode Ports: #3 ~ #4

VLAN Mode Ports: #1 ~ #4

MAC Address Table: 2048

Max Switching Capacity: 12 Gbps

Max Forwarding Rate: 8.928 Mpps

Jumbo Frame: 9 KB

Packet Buffer: 1 Mbit

802.3 Protocols

• 802.3i 10BASE-T
• 802.3u 100BASE-TX
• 802.3ab 1000BASE-T
• 802.3z 1.25 Gbps over Fiber
• 802.3x Flow Control
• 802.3af PoE
• 802.3at PoE
