General Data
Maximum Efficiency: 97.60%
MPPT Efficiency: 99.90%
Paralleling: 10 Units On-Grid / Off-Grid
Generator Compatible
Mounting: Wall Mount
Battery Input Data
Battery Type: Li-Ion
Battery Voltage Range: 160VDC to 800VDC
Maximum Charging Current: 50A + 50A
Maximum Discharging Current: 50A + 50A
Number Of Battery Input: 2
Charging Strategy for Li-Ion Battery: Self adaption to BMS
PV String Input Data
Maximum DC Input Power: 65000W
Maximum DC Input Voltage: 1000VDC
Startup Voltage: 180VDC
MPPT Voltage Range: 150VDC to 850VDC
Full Load DC Voltage Range: 450VDC to 850VDC
Rated DC Input Voltage: 600VDC
PV Input Current: 36A + 36A + 36A + 36A
Maximum PV (Isc): 55A + 55A + 55A + 55A
No of MPP Trackers: 4
Strings per MPP Tracker: 2
AC Output Data
Rated AC Output and UPS Power: 50000W
Maximum AC Output Power: 55000W
AC Output Rated Current: 75.8A / 72.5A
Maximum AC Current: 83.3A
Maximum Continuous AC Passthrough: 150A
Peak Power (Off Grid): 1.5 time of rated Power, 10S
Generator Input: 75.8A
Smart Load: 150A
AC Couple Current: 75.8A
Power Factor: 0.8 Leading to 0.8 Lagging
Output Frequency and Voltage: 50/60Hz; 3L/N/PE 220/380VAC, 230/400VAC
Grid Type: Three Phase
Environment Limit
Operating Temperature Range: -40C to 60C
Cooling: Smart Cooling (<45 dB)
Communication with BMS: RS485 / CAN
Ingress Protection: IP65
Safety Certification: IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2
