DJPOWER DFZ-800 HAZE MACHINE 1200W

DFZ-800 is a durable and super quiet version developed particularly for high-end bars, professional installations and small performances. It features a range of upgrades to ensure it remains the top haze machine in its class. An improved and new fast heater ensures all fluid is vaporized quickly as well as shorter heat-up time, 50 seconds only.

AC POWER
Input Voltage & Rate: 220-240 V, 50/60 Hz

Current Limiter Type: Fuse (F)

Current Limiter Specifications: 8 A, 250 V

Total Power Consumption: 1,200 W

Operating Current: 5.2 A

Power Input Connector: IEC

HEATING
Heat Up Time: Appr. 50 s

Heater Type: Fast Coil Heater

CAPACITY
Fluid Tank Capacity: 3 L

OUTPUT
Adjustable Volume:

Volume Adjustment Level/Range: 1-100%

Max Output Volume: Appr. 6,000 cuft/min

Fluid Consumption @ full volume : Appr. 167 min/L

Maximum Continuous Duration @ full volume: Unlimited

Continuous Output :

Max Continuous Output Level: 100%

Fully-loaded Cumulative Output Duration @ full volume: Appr. 437 min

Consumable Type for Standard Output Test: PRO-C/PRO-J

FEATURES
Physical Thermostat:

Electronic Thermo-Control:

Adjustable Output :

Adjustable Fan Speed:

No-Fluid Protection:

CONTROL
On-device Manual Control: LCD control board

Wireless Control: W-4 / RF 433MHz / Built-in

Wired Control: ×

Control Protocol: DMX-512

DMX Channel Range: 2

Data Connectors: 3-pin and 5-pin XLR

ACCESSORY
Power Cord:

Wireless Controller Model: W-4 / RF 433MHz / Transmitter

Wired Controller Model: ×

CONSUMABLE
Consumable: PRO-C or PRO-J Haze Fluid

WEIGHT & DIMENSIONS
Net Weight: 11 kg

Gross Weight: 12.6 kg

Machine Dimensions: 379 × 310 × 286 mm

Packing Dimensions: 445 × 445 × 410 mm
