Dyness 5.12kW Lithium Battery DL5.0C

Dyness 5.12kW Lithium Battery DL5.0C

Product Highlights:

• Battery Type: Lithium Iron Phosphate (LiFePO4)
• Nominal Battery Energy: 5.12kWh
• Nominal Capacity: 100Ah.
• Nominal Voltage: 51.2V
• Operating Voltage Range: 44.8V 57.6V
• Recommended C Rate: 1C (Optimal charge and discharge rate)
• Recommended Charge / Discharge Current: 50A (Safe operating current)
• Maximum Power Charge Current: 75A (Maximum charge rate)
• Maximum Power Discharge Current: 100A (Maximum discharge rate)
• Peak Power Charge / Discharge Current: 110A (15 seconds, for short bursts)
• Depth of Discharge: 90% (Safe discharge depth)
• Charging Temperature Range: 0°C to 55°C (Ideal charging conditions)
• Discharging Temperature Range: -20°C to 55°C (Wide operational temperature range)
• Communication: CAN / RS485 / RS232 (Supports various communication protocols)
• Mounting: Wall Mount & Rack Mount (Flexible installation options)

Safety Rules for Installation and Operation:

1. Professional Installation: Always consult a professional for correct installation and adherence to safety standards.
2. Proper Ventilation: Ensure proper ventilation in the installation area to prevent overheating.
3. Temperature Management: Operate the battery within the specified temperature range for optimal safety and performance.
4. Regular Inspection: Periodically inspect the battery for any signs of damage or abnormal operation. Maintenance should be performed by qualified technicians.

General Applications:

• Home Energy Storage: Ideal for storing excess energy generated by renewable sources like solar panels, ensuring power availability during outages or when energy demand is high.
• Commercial Energy Backup: Provides reliable backup power for businesses during grid failures or as a supplement during peak energy consumption periods.

The Dyness 5.12kW Lithium Battery DL5.0C offers a robust energy storage solution with advanced features for a range of applications, from residential to commercial settings. Its safety measures and flexible installation options make it a dependable choice for powering your energy needs.

Documents

Dyness 5.12kW Lithium Battery DL5.0C datasheet
