Specifications:
Connector: JST GH1.25 Connector
PWM Output: 10 PWM Output
Mavlink UART: 2(without CTSRTS)
USB Port: 1(Type-C)
GPS UART/I2C Port: 1
RC In Signal Input: PPM/SBUS
RSSI Output: Do not support
OSD Module: OSD Module Integrated
ESC Protocol: PWM
DSHOT Protocol: Do not support
ONESHOT Protocol: Do not support
Neopix Led: Support
Gripper Function: Support
RTKSupport
USB Voltage: 5V±0.3V
Servo Voltage: Not applicable
Operating Temperature: -40~80
Adaptable Models: 3-8 copter/Airplane/Helicopter/Car/Boat
Dimention: 39.7*39.7*13mm (1.56'*1.56'*0.51')
Weight: 16.5g(0.58oz), 54g(1.9oz when all the connect wires included)
Power Module Specifications:
Input Voltage: 2-12S
Input Current: 90A
Output Voltage: 5.1V
Output Current(BEC): 2.5A
Input Current(connect to one ESC only): 20A
Hardware Specification:
Processor: HC32F4A0PITB
