GeeWiz VMIV 5.6KW Pure Sine Wave Solar Inverter - 5600VA / 5600W

Please note, the AC / Solar charging circuit on this unit is quite noisy, please do not install this unit in a sound sensitive environment.

• 5600W Rated Output Power
• 6000W Solar Panel 120A MPPT Input (500V High Voltage)
• 48V DC Battery Voltage
• NO Parallel Capability
• Can work on solar only (no battery)
• BUILT-IN Wi-Fi for mobile monitoring (App is available)

• Customizable status LED ring with RGB lights
• 4.3" colour touch LCD display
• Built-in anti-dust kit
• BMS comms port

Features

Customizable status LED ring with RGB lights
Touchable button with 4.3" colored LCD
Built-in Wi-Fi for mobile monitoring (App is available)
Supports USB On-the-Go function
Data log events stored in the inverter
Reserved communication port (RS485, CAN-BUS or RS232) for BMS
Battery independent design
Battery equalization extends lifecycle
User-friendly LCD operation
Enhanced charging power
Built-in anti-dust kit

Specifications

Rated Power: 5600VA/5600W

INPUT

Voltage: 230 VAC
Selectable Voltage Range: 170-280 VAC (For Personal Computers), 90-280 VAC (For Home Appliances)
Frequency Range: 50 Hz/60 Hz (Auto sensing)

OUTPUT

AC Voltage Regulation (Batt. Mode): 230 VAC ± 5%
Surge Power: 11200VA (for VM IV 5600-48)
Efficiency (Peak): 90% ~ 93%
Transfer Time: 15 ms (For Personal Computers), 20 ms (For Home Appliances)
Waveform: Pure sine wave

BATTERY

Battery Voltage: 48 VDC (for VM IV 5600-48)
Floating Charge Voltage: 54 VDC (for VM IV 5600-48)
Overcharge Protection: 63 VDC (for VM IV 5600-48)

SOLAR CHARGER & AC CHARGER

Solar Charger Type: MPPT
Maximum PV Array Power: 6000 W (for VM IV 5600-48)
MPPT Range @ Operating Voltage: 120 ~ 450 VDC
Maximum PV Array Open Circuit Voltage: 500 VDC
Maximum Solar Charge Current: 120 A
Maximum AC Charge Current: 100 A
Maximum Charge Current: 120 A

PHYSICAL

Dimension, D x W x H (mm): 119 x 313.6 x 422.8
Net Weight (kgs): 12.0 (for VM IV 5600-48)
Communication Interface: USB/RS232/RS485/WiFi/Dry-contact
