Sacolar Inverter - WiFi compatible- 5kVA / 5kW Pure Sine Wave 48V Solar Inverter, 100A High Volta...

Sacolar Inverter - WiFi compatible- 5kVA / 5kW Pure Sine Wave 48V Solar Inverter, 100A High Voltage MPPT / Parallel

IP Rating:

• IP20
• Not recommended for installation location with high humidity
• If the inverter needs to be installed close to the ocean please make use of a dehumidifier

Built-in:

• 100A MPPT high voltage charge controller (from PV)
• Inverter charger (grid to battery, solar to battery)
• Bypass for grid to usage

Max Watt Output:

• Continuous: 5kW / 5kVA
• Surge (5 seconds): 10kW

Charging Source Settings:

• Can be set: Solar first, grid first, solar & grid, solar only
• Solar only: 100A (maximum)
• Grid only: up to 80A
• Combination solar & grid: up to 140A

Solar Input  Specifications:

• PV Maximum input current: 20A
• MPPT Voltage range: 120 to 430Vdc
• PV Panels MINIMUM: 500W
• PV Panels maximum: 5500W

Output (discharge) Source:

• Solar first - Can be set
• Utility first (bypass) - Can be set
• Prioritized solar/battery/utility - Can be set
• Solar and utility joint

Dimensions:

• Boxed : 60cm L x 43cm W x 24cm H at 14kg
• Unit : 54.5cm L x 40.5cm W x 22cm H at 12kg

Monitoring & Setting:

• Computer Connection: Serial port
• LCD screen
• WiFi / GPRS remote monitoring (Optional)
• CAN & RS485 port for BMS communication

• Communication with The Sun Pays LiFePO4 battery via RS485 port.

Expansion: Single Inverter

• PV Panels minimum: 500W
• PV Panels maximum: 5500W
• Batteries minimum: 4 x 100Ah 12V
  or 1 x 48V LiFePO4

• Peak Efficiency: 93%
• No Load Power Consumption: <50W

Expansion: More Inverters

• Single-phase: Up to 6 units = 30kVA
• Three-phase: Up to 6 units in total. Different configurations, maximum 2 units per phase (2 + 2 + 2).
• Please take note that the warranty will only be valid for up to 3 inverters connected in parallel. Contact us for approval on warranty for more than 3 inverters connected in parallel.


IMPORTANT : THE CORRECT SETTINGS ON THE INVERTER WILL AID IN ENSURING OPTIMAL BATTERY LIFE. HERE IS A GUIDE ON INVERTER SETTINGS FOR THE LiFePO4 battery. HERE IS A GUIDE ON INVERTER SETTINGS FOR THE AGM / Gel battery.

Warranty:

• Please take note of the full warranty terms and conditions.
• Please take note that the warranty will only be valid for up to 3 inverters connected in parallel. Contact us for approval on warranty for more than 3 inverters connected in parallel.

This checklist can be used to assist with single inverter installation and parallel inverter installation.

**FREE DELIVERY NATIONWIDE!!!**

Free nationwide delivery on inverters. Please take note for warranty claims that transport to The Sun Pays office will be the customer's cost.
