Solar Inverter - 6.2kW 7kVA High Voltage, 48V, Pure Sine wave Inverter, Stand alone ONLY

6.2kW / 7kVA 48V High Voltage Hybrid Off-Grid Inverter Pure Sine Wave, WiFi Compatible, Non-Parallelable / Non-Expandable

MODEL SP-7000

User manual available here

IP Rating:

• IP21
• Not recommended for installation location with high humidity.
• If the inverter needs to be installed close to the ocean please make use of a dehumidifier.

Features:

• Programmable supply priority for PV, Battery or Grid.
• Wide PV input range 55 - 450VDC.
• Stand alone unit, CANNOT be connected in parallel.

• Cold start function.

Max Watt Output:

• Continuous: 7kVA / 6.2kW
• Surge: (5 seconds) : 12.4kW

Output and Charging Source Settings:

• Solar-Utility-Battery & Solar-Battery-Utility.

• Solar only: 110A (maximum).
• Grid only: up to 80A.

Solar input specifications:

• 55 - 450Vdc solar input is the optimal working voltage range for these inverters.

• 20A max input from Solar Panels.

Monitoring & Setting :

• LCD screen.
• Wi-Fi dongle (optional) monitoring system via SmartESS phone app.


Expansion: Single Inverter

• PV Panels minimum: 450Voc
• PV Panels maximum: 6 000W
• PV Panels connection : series only.
• 20A max input from Solar Panels.
• Batteries minimum: 4 x 100Ah 12V / 48V LiFePo4
• Peak Efficiency: 94%
• No Load Power Consumption: <50W

Expansion: More Inverters

• Can ONLY be used as single inverter.

 Physical dimensions

• 423 x 290 x 105mm
• 7.5KG

What's in the box

• Inverter
• User manual

IMPORTANT: THE CORRECT SETTINGS ON THE INVERTER WILL AID IN ENSURING OPTIMAL BATTERY LIFE.

Warranty:

12 Months Warranty

Please take note of the full warranty terms and conditions.

**FREE DELIVERY NATIONWIDE!!!**

Free nationwide delivery on inverters. Please take note, transport costs of warranty claims to The Sun Pays' Rayton office will be at the cost of the customer.
