Gigabyte Intel Z790 Eagle AX Intel 12th / 13th / 14th Gen Socket LGA 1700 ATX Motherboard, Intel Z790 Express Chipset, 4 x DDR5 DIMM Memory slots, 1x HDMI Port, 1 x DisplayPort, Realtek 2.5GbE LAN Chip, Intel Wi-Fi 6E AX211, Bluetooth 5.3, 1x PCI Express x16 slot supporting PCI-e 5.0 and running at x16, 1x PCI Express x16 slot supporting PCI-e 4.0 and running at x, 2x PCI Express x1 slots supporting PCI-e 3.0 and running at x1, 3x M.2 connectors PCIe 4.0 x4/x2, 4x SATA 6Gb/s connectors, USB Type-C Port with USB 3.2 Gen 2 support, USB Type-C Port with USB 3.2 Gen 1 support, USB 3.2 Gen 2 Type-A Port, USB 3.2 Gen 1 Ports, USB 2.0/1.1 Ports, 1x Q-Flash Plus Button, 1x PS/2 Keyboard/Mouse Port, 2 x SMA antenna connectors, 3x audio jacksOverview:Z790 EAGLE AX (rev. 1.0)Supports Intel Core 14th/ 13th /12th processorsUnparalleled Performance:Twin 12*+1+? Phases Digital VRM SolutionDual Channel DDR5:4*DIMMs with XMP 3.0 Memory Module SupportNext Generation Storage:3*PCIe 4.0 x4 M.2 ConnectorsAdvanced Thermal Design & M.2 Thermal Guard: To Ensure VRM Power Stability & M.2 SSD PerformanceEZ-Latch:PCIe 5.0x16 Slot with Quick Release DesignFast Networks:2.5GbE LAN & Wi-Fi 6E 802.11axExtended Connectivity:DP, HDMI, Rear USB-C 10Gb/sSmart Fan 6:Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOPQ-Flash Plus:Update BIOS Without Installing the CPU, Memory and Graphics Card* 6+6 phases parallel power designFeatures:Durable PerformanceGIGABYTE Ultra Durable motherboards built with optimal components inside out provide the prime performance and timeless platform.The best VRM design ever built with the highest quality components.12+1+1 Phases digital PWM + Low RDS(on) MOSFETsSupport the latest CPUs, and deliver enhanced system performance and ultimate hardware scalability.Unlock DDR5 VoltageGIGABYTE Exclusive DDR5 Circuit Design Increases DDR5 memory overclocking performance and capability by transforming Native DDR5 memory module to Overclocked DDR5 memory.Secure ModeMotherboard provides fixed 5V to Native DDR5 memory and built-in PMIC outputs locked 1.1v to memory IC.Unlocks Native DDR5 PMIC secure mode into programmable mode and controls Native DDR5 voltage with wide range.Supports all PMIC vendors for maximum compatibilityAchieve Higher DDR5 Memory Frequencies with EaseDDR5 XMP Booster function provides optimized pre-defined profiles, based on memory IC and PMIC vendor analysis, for effortless performance enhancement and elimination of manual configuration for overclocked DDR5 memory kits.XMP 3.0 User Profile empowers you to optimize your memory settings and achieve the best performance for your system.SPD Re-defined or retrieve from database Users can define two empty SPD profiles and transfer them to another computer.Performance Simulation Simulate memory performance quickly by inputting clock and timing parameters.Save/Load Profile Save and load memory profiles for online sharing.Boost non-overclockable DDR5 memory frequency Increase the frequency of non-overclockable DDR5 memory.One-click Clear Profile Reset memory settings conveniently.M.2 Thermal GuardThe M.2 Thermal Guard prevents throttling and bottlenecks from high speed M.2 SSDs as it helps to dissipate heat before it becomes an issue.6-Layer & 2X Copper PCB2X copper PCBs design effectively lower the component temperature by its high thermal conductivity and low impedance.Future ConnectivityThe ultimate connectivity with blazing data-transfer speeds through the next generation network and storage.802.11ax Wi-Fi 6EThe latest Wireless solution 802.11ax Wi-Fi 6E with new dedicated 6GHz band, enables gigabit wireless performance, provides smooth video streaming, better gaming experience, few dropped connections and speeds up to 2.4Gbps. Moreover, Bluetooth 5 provides 4X range over BT 4.2 and with faster transmission.2.5GbE LANSupercharge your gaming with 2.5GbE LAN Achieve lightning-fast speeds, minimal lag, and unbeatable performance to elevate your gaming setup and dominate the competition.PCIe 5.0 / 4.0 Hardware DesignFeaturing PCIe 5.0 x16 slot and PCIe 4.0 M.2 slot support, GIGABYTE Motherboards are ready to work with the PCIe 5.0/ 4.0 devices to provide the superior performance.High-End Audio CapacitorsThese high quality capacitors help deliver high resolution and high fidelity audio to provide the most realistic sound effects.Audio Noise GuardEssentially separates the board's sensitive analog audio components from potential noise pollution at the PCB level.Easy FriendlyInnovative and intuitive hardware, software, and BIOS interface design to create your personal style.EZ-LatchUnlock the latch of the PCIe slot easily when remove the graphics card in the PCIe slot.Q-Flash PlusUpdate the BIOS easily without installing the CPU, memory, and graphics card.STEP 1: Plug the 24-pin and 8-pin power supply cables into the motherboard.STEP 2: Download the motherboard BIOS file and rename it to "gigabyte.bin". Save it to a USB flash drive formatted in FAT32 . Insert the USB flash drive into the Q-FLASH PLUS USB port.STEP 3: Press the Q-FLASH PLUS button, and the motherboard will start updating the BIOS automatically.Smart Fan 6ensures optimal cooling and quiet operation for your gaming PC, with support for PWM/DC fans and pumps, customizable settings, and intuitive temperature monitoring.High Current Support: Each fan headers support PWM and DC fan and Water Cooling Pump, and up to 24W (12V x 2A) with Over-Current Protection.Precision Control: Multiple temperature/fan speed control points for precise fan curve.Dual Curve Mode: Slope/Stair dual mode for different user scenario.Fan Stop: Fan can stop completely below users' specified temperature point.Smart Fan 6 BIOS UIEnhance Fan Curve UI : Enhance fan curve control with an expanded number of control points, from 5 to 7, and a larger fan speed graph, enabling users to have more precise and effortless control over fan curve settings.Slope/Stair Dual Graph Mode : Switch between Slope and Stair modes to adapt to various user scenarios. Slope mode provides a linear fan speed curve, while Stair mode maintains a constant fan speed within specified temperature intervals.Manual Input : For advanced users, manual input of fan speeds is available for fine-tuning and precise control over the cooling system.EZ Tuning : Simplify the process with EZ Tuning by setting 4 points on a rough temperature/fan speed scale. Smart Fan 6 will quickly generate a fan curve based on these points.Fan Curve Profile : Save your customized fan curve profile in the BIOS ROM, ensuring it remains intact even after BIOS updates.Redesigned UI and UXan intuitive operation interface with an aesthetically pleasing design.Quick Access9 customizable option slots for effortless access in Easy Mode.PerfDriveexclusive BIOS settings that optimize the performance based on the cooling configurationGIGABYTE Control CenterUnified software platform for all Gigabyte supported products.Specifications:L3 cache varies with CPUChipset Intel Z790 Express ChipsetMemory 14th and 13th Generation Intel Core i9/i7 Pocessors:- Support for DDR5 7600(O.C.) /7400(O.C.) /7200(O.C.) /7000(O.C.) /6800(O.C.) /6600(O.C.) / 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5800(O.C.) / 5600 / 5400 / 5200/ 4800/4400 MT/s memory modules13th Generation Intel Core i5/i3 and 12th Generation Intel Core, Pentium Gold and Celeron Processors:- Support for DDR5 4800/4
