Specifications:
Brand: GXservo
Control system: PWM control system
Temperature range: -20 - +60
Voltage range: 6.0V - 7.4V
Test voltage: AT 6.0V / AT 7.4V
Torque: 22KG.CM / 25KG.CM
Speed: 0.2s/60°, 0.18s/60°
No-load current: 300MA/450MA
Load current: 180OMA/2400MA
Dead zone width: 2 microseconds
Cycle: >15000 TIMES
Working angle: 90°±5°
Direction: Counterclockwise Pulse 1500 TO 2500 USEC
Drive mode: field effect transistor drive
Motor type: Iron core motor 1723
Potentiometer: indirect transmission
Amplifier Type: Digital
Size: 40*20*39MM
Weight: 60G (excluding accessories)
Ball Bearing: Double Ball Bearing
Gear material: imported copper steel material
Packing included
1x Digital Servo
1x Arm
1x set of Accessories
Note:
(1) Under the static working current, servo is energized, but there is no mo
