Harwin (M20-8761042) Pin Header, Vertical, Wire-to-Board, 2.54 mm, 2 Rows

Pin Header, Vertical, Wire-to-Board, 2.54 mm, 2 Rows, 20 Contacts, Surface MountStraight, M20-87Product OverviewThe M20-8761042 is a 20-contact 2.54mm male DIL Wired-to-board Pin Header with100% tin over nickel plated phosphor bronze contacts, gold plated terminationand black UL94V-0 polyamide (nylon) 6T housing. The M20 series connector has 3mmsolder PC tails, vertical connector orientation and surface mount (SMT)connection type. It is suitable for use with 0.64mm square mating pin size.Suitable for interconnecting wired to board.3A Maximum Current rating250VAC/DC Voltage rating20mR Maximum contact resistance500MR Minimum insulation resistance1000VAC Dielectric strength50 operations (tin), 300 operations (gold) DurabilityApplicationsCommercial, IndustrialProduct InformationConnector Systems: Wire-to-BoardPitch Spacing: 2.54mmNo. of Contacts: 20ContactsContact Termination Type: Surface Mount StraightNo. of Rows: 2RowsProduct Range: M20-87Contact Material: BrassContact Plating: Gold Plated Contacts
