Product details

Condition
New
Location
International
Bob Shop ID
606996929

SELECTED OPTION:
FREQUENCY: 433MHZ

Introduction:

The Pixhawk 4 S500 V2 Basic Kit is the perfect way to get started developing on Pixhawk 4 . It pairs a 480mm wheelbase?racing frame?and essential electronics with a Pixhawk 4 autopilot. The kit is easy to assemble. No soldering needed.S500 V2 Update:1.Motor:2216 880kv; 2.Propeller 1045; 3.Motor mouts reinforced.


Description:

Brand: Holybro

Model:?S500 V2 Kit (?Pix32 V5 Ardupilot Version)

Item Name: ?480mm Wheelbase 10 Inch Frame Combo

  • Pix32 V5 ardupilot
  • Pix32 V5-Base board
  • Power Management?PM02???Assembled???
  • ARM adopts high strength plastics
  • Motors - 2216 KV880??? V2 Update???
  • BLHeli S ESC 20A
  • Propeller 1045??? V2 Update???
  • Pixhawk4 GPS
  • Fully assembled Power Management Board with ESCs
  • 433MHz Telemetry Radio / 915MHz Telemetry Radio
  • Power and?Radio Cables
  • Battery Straps
  • Dimensions:383*385*240mm
  • Wheelbase:480mm
  • Weight:985g

Note:? No LiPo battery included.

Recommended Battery Specification: 4S 5000mAh Lipo

Max payload: up to 1.8kg (4S 5000 mAh battery)


Spare Parts-S500 Specification

1045 Propeller

Item Name: 1045 10 Inch 2-Blade Prop

Quantity: 2 CW & 2 CCW

S500 Frame Kit

Item Name: 480mm Wheelbase Frame

2216 880KV Motor

Item Name: 2216 880KV Motor

Quantity: 2 CW & 2 CCW

20A BLHeli_S ESC

Item Name: 20A BLheli_S ESC
Con.?Current:20A
Burst?Current(10S): 30A
BEC: NO
LiPo?cells: 2-4S

Quantity: 4 PCS
BLHeli-S?is?using?the?A-H-30?BLHeli-S?firmware



Manual:

?( Take example as S500 V2? Pixhawk 4 Version, NOT this PIX32 V5 Version)

?

Package Included:

1x Holybro S500 V2 Pix32 V5 Ardupilot Kit
