Honeywell (2455R--01000078) Thermostat Switch, Commercial, 2455R Series

Thermostat Switch, Commercial, 2455R Series, 50 °C, Normally Open, Flange MountProduct OverviewThe 2455R-100-78 is a commercial Bimetal Thermostat with phenolic base andsilver alloy contact. It can provide either temperature control orover-temperature protection by breaking electrical contact when a specifiedtemperature is reached. Single pole, single throw, snap-acting, non-adjustablethermostat which may be used in applications such as power supplies, generalappliances and medical equipment. A temperature-sensitive bimetal disc. Contactsopen when surface or ambient temperatures increase to the operating set point ofthe calibrated bimetal disc. The entire switch is enclosed in a phenolichousing, the bimetal disc is retained by a metal heat-conducting end cap. Due tothe small size of this unit and the inherently low mass of the bimetalsnap-action disc.0 to 150°C Operating temperature rangeApplicationsSensing & Instrumentation, Power Management, Consumer Electronics, Medical,Commercial, Industrial, HVACProduct InformationSwitching Temperature: 50°CReset Temperature: 35°CContact Operation: Normally OpenSensor Terminals: Quick ConnectSensor Housing: Flange MountContact Rating: 120VAC/15A, 240VAC/10AProduct Range: 2455R Series
