Product details

Condition
New
Location
International
Bob Shop ID
651231151
Description:
JKM NEMA23 1.8ᆪ57 Hybrid Stepper Motor Two Phase 56mm 12kg.cm 2.8A Step Motor

Specification:

Brand JKM
Model 57HS51-2804
Motor length 51mm
Diameter of axle 6.35mm
The front shaft length 21mm
Size 57x57x51mm
Holding Torque 10.1kg.cm
Outgoing line 300mm
Certification Certification: CE,ROHS
Scope 3D Printers, Monitor Equipment, Medical Machinery, Textile Machinery, Packaging Machinery, Stage Lighting,ect.

Genaral Specification:
Item Specifications
Step Angle 1.8ᆪ
Temperature Rise 80amax
Ambient Temperature -20a~+50a
Insulation Resistance 100 MMin. ,500VDC
Dielectric Strength 500VAC for 1minute
Shaft Radial Play 0.02Max. (450g-load)
Shaft Axial Play 0.08Max. (450g-load)
Max. radial force 75N (20mm from the flange)
Max. axial force 15N

Electrical Specifications:
Model No. Step Angle Motor Length Rate Voltage
/Phase
Current
/Phase
Resistance
/Phase
Inductance
/Phase
Holding Torque # of Leads Detent Torque Rotor Inertia Mass
( ᆪ) (L)mm V A mH kg.cm No. g.cm g.cm Kg
57HS51-2804 1.8 51 2.3 2.8 0.83 2.2 10.1 4 350 280 0.59



Package Included:
1 x Motor

More Details:
