Kemet (T499A335K006ATE8K0) Surface Mount Tantalum Capacitor, 3.3 µF, 6.3 V

Product InformationCapacitance: 3.3µFVoltage(DC): 6.3VCapacitor Case / Package: 1206 [3216-18 Metric]Capacitance Tolerance: ± 10%ESR: 8ohmManufacturer Size Code: ASeries Name: T499Case Size: 1206Product Diameter: -Product Height: 1.6mmProduct Range: T499Product Length: 3.2mmOperating Temperature Min: -55°CProduct Width: 1.6mmOperating Temperature Max: 175°CSupplier Package: 1206 [3216-18 Metric]Automotive Qualification Standard: AEC-Q200Product OverviewThe T499 series SMD Tantalum Capacitor offers optimum performancecharacteristics in applications with operating temperatures up to 175°C.Advanced materials and testing allow this series to perform with a reliabilitylevel of 0.5%/1000hrs at rated voltage and temperature.Meets or exceeds EIA Standard 535BAACSymmetrical and compliant terminationsOptional gold-plated terminationsLaser-marked case100% surge current test available on all case sizesComplies with AEC-Q2000.15 to 220µF Capacitance range6 to 50V Voltage range
