NavaSolar X3024 3KW 24V Off-Grid Solar Inverter 60A MPPT NV-X3024

Inverter Specs

• Output power factor up to 1.0
• Compatible to AC mains or generator inputs
• Considerable PV input types
• Build-in smart solar charger (PWM/MPPT)
• Battery independent design(5kW)
• Auto restart while AC is recovering
• Configurable AC/Solar input priority via LCD setting
• Selectable input voltage range for home appliances and personal computer loads

Key Specifications
Model : NV-X3024
Rated Power : 3000W / 3000KVA

Input
Voltage : 208/220/230/240VAC
Selectable Voltage Range : 170- 280 VAC (For Personal Computers) | 90- 280 VAC (For Home Appliances)
Frequency Range : 50 Hz/60 Hz (Auto sensing)

Output
AC Voltage Regulation (Batt. Mode) : 230VAC ± 5 %
Surge Power : 6000W
Effiency (Peak) : 93.5%
Transfer Time : 10 ms
Waveform : Pure sine wave

Battery And AC Charger
Battery Voltage : 24VDC
Floating Charge Voltage : 27.4VDC
Overcharge Protection : 30VDC

Solar Charger
Maximum PV Array Power : 1500W
MPPT Range - Operating Voltage : 30~115VDCVDC
Maximum PV Array Open Circuit Voltage : 145VDC
Maximum Solar Charge Current : 60A
Maximum AC Charge Current :60A
Maximum Charge Current : 60A

Battery Specs:

Prismatic Lithium
IP Grade: IP65
Charge Current: 50A
Max Charge Current: 100A
Max Continuous Discharge Current: 100A
Recommended Charge Voltage: 27.2~27.6V
Overcharge Protection Voltage: 29.6~30.0V
Discharge Cut-off Voltage Range: 17.6V
Nominal Voltage: 25.6V
Nominal Capacity: 100Ah
