Panasonic (16SEPC100M) Polymer Aluminium Electrolytic Capacitor, 100 µF

Polymer Aluminium Electrolytic Capacitor, 100 µF, 16 V, Radial Leaded, 0.024 ohmProduct InformationCapacitance: 100µFVoltage Rating: 16VVoltage(DC): 16VAE Capacitor Case: Radial LeadedCapacitor Case / Package: Radial LeadedESR: 0.024ohmLifetime @ Temperature: 5000 hours @ 105°CCapacitance Tolerance: ± 20%Product Diameter: 6.3mmProduct Height: 6mmDiameter: 6.3mmSeries Name: OS-CON SEPCHeight: 6mmCapacitor Terminals: Radial LeadedProduct Length: -Product Width: -Supplier Package: -Operating Temperature Min: -55°COperating Temperature Max: 105°CProduct Range: OS-CON SEPCAutomotive Qualification Standard: -Product OverviewThe 16SEPC100M is a radial leaded Electrolytic Capacitor with high conductivepolymer. A conductive polymer has a temperature characteristic, which is littlechange against temperature for the ESR and capacitance. The OS-CON acquires lowEquivalent Series Resistance (ESR), excellent noise reduction capability andfrequency characteristics. In addition, OS-CON has a long lifespan and its ESRhas little change even at low temperatures since the electrolyte is solid.Low ESR obtained by using conductive polymer electrolyteHigh voltage and high reliability2490mA RMS at 100kHz/105°C Rated ripple current320µA Maximum leakage current (after 2 minutes)
